Get started

On this page you run your first simulation and learn to read its results.

Before you start

You need uv. uv installs the right Python version and all the packages SBS needs.

Run your first simulation

git clone https://github.com/GiorgDiama/SymBChainSim.git
cd SymBChainSim/src/Simulator
uv run Blockchain.py

This runs the default configuration simulates a blockchain of 16 nodes running PBFT for 1800 seconds. You will get to explore the configuration options of SBS a bit later.

Run SBS from src/Simulator

SBS finds its config files relative to this folder. Run all commands in these docs from here.

Make it shorter

You can change any setting from the command line with --set. For quick tests, simulate 300 seconds instead of 1800:

uv run Blockchain.py --set simulation.sim_time=300

Read the output

This is the output of the short run:

SymBChainSim | PBFT | 16 nodes | 300 s | seed 1837413

0 / 300 s                 0 blocks           0 tx
100 / 300 s              66 blocks      11,760 tx
200 / 300 s             131 blocks      23,858 tx
300 / 300 s             197 blocks      35,880 tx

 RESULTS (mean over 16 nodes)
  Blocks                   197  (PBFT 197)
  Transactions             35,880 confirmed, 120 pending
  Throughput               119.8 tx/s
  Mean latency             2.06 s
  Mean block time          1.52 s
  Mean block size          0.44 MB
  Decentralisation (Gini)  0.16 (0 = perfectly decentralised)

Snapshots → Outputs/Snapshots/snapshot.json (plot with ScenarioGenerationAndVisualisation/snapshot_visualisation.ipynb)
Finished in 2.9 s

The output has four parts.

1. The header shows the setup: the consensus protocol, the number of nodes, the simulated time and the random seed.

2. The progress lines appear every 100 simulated seconds. They show the blocks and the transactions confirmed so far.

3. The results. Every node keeps its own copy of the blockchain. SBS measures each copy and shows the mean over all nodes.

Row Meaning
Blocks Blocks added to the chain. The brackets show how many each protocol made.
Transactions Confirmed transactions are in a block. Pending transactions are waiting for one.
Throughput Confirmed transactions per second.
Mean latency Time from when a transaction is created until its block is added to the chain.
Mean block time Time between two blocks.
Mean block size Size of a block, in MB.
Decentralisation (Gini) How evenly the nodes share the work of making blocks. 0 means every node made the same number of blocks. 1 means one node made all of them.

4. The snapshots line tells you where SBS saved data over time. You plot it in the first tutorial.

Naming results

You can use --name <name> to set the name of the output file.

Changing the default configuration

Try a different consensus protocol with --cp:

uv run Blockchain.py --set simulation.sim_time=300 --cp Tendermint

Or send more transactions than PBFT can handle:

uv run Blockchain.py --set simulation.sim_time=300 --set application.tx_per_sec=200

  Transactions             49,070 confirmed, 10,930 pending
  Throughput               165.0 tx/s
  Mean latency             27.82 s

PBFT confirms about 165 transactions per second here. The other transactions wait, so the transaction confirmation latency grows.

Every --set names a setting as group.name. You can find all the settings, with comments, in src/Configs/base.yaml. Configuration explains how the config files work.

See more detail

Add -v to also print the nodes, the parameters, the results of each node and the number of events:

uv run Blockchain.py --set simulation.sim_time=300 -v

uv run Blockchain.py --help lists all the command-line options.
